Commercial

Application : Industrial

Input :

208V AC/400V AC, 3-Phase

Output :

0 to 100V DC / 0 to 50A

Features :

• Wide range of input operations
• 19” Rack Mountable
• Low output Ripple & Noise
• Built-in RS-232/RS-485 Interface
• High Resolution 16 bit ADCs & DACs
• Constant Voltage/Constant Current
• Voltage and Current Adjustment
• High Power Density 5kW in 2U

• Remote & local mode operation
• Remote Compensation
• External Analog Programming
• Front Panel Lock selectable
• Health Status indications
• Last-Setting Memory
• Auto-Re-Start / Safe-Start
• Rugged & Highly reliable

Features :

• Designed for EN55022A, FCC part 15-A
• Designed for MIL-STD-810F
• Operating Temp: -20°C to +65°C
• Active PF Correction (≥ 0.98)
• Remote Compensation
• Isolated Outputs, Standard
• Low output Ripple & Noise
• Health Status indications
• Rugged & Highly reliable

Application :

Industrial

Input :

230V AC (180V to 264V AC)

Output :

+24V DC / 100A

Application : Industrial

Input :

110V AC/230V AC, 1-Phase

Output :

0 to 60V DC / 0 to 40A

Features :

• Wide range of input operations
• 19” Rack Mountable
• Low output Ripple & Noise
• Built-in RS-232/RS-485 Interface
• High Resolution 16 bit ADCs & DACs
• Constant Voltage/Constant Current
• Voltage and Current Adjustment
• High Power Density 2.4KW in 2U

• Remote & local mode operation
• Remote Compensation
• External Analog Programming
• Front Panel Lock selectable
• Health Status indications
• Last-Setting Memory
• Auto-Re-Start / Safe-Start
• Rugged & Highly reliable

Features :

• Wide Input Operating Range
• Designed for EN55022A, FCC part 15-A
• Designed for MIL-STD-810F
• Operating Temp: -20°C to +65°C
• Isolated Output, Standard
• Low output Ripple & Noise
• Epoxy Sealed
• Rugged & Highly reliable

Application :

Industrial

Input :

230V AC (90V to 264V AC)

Output :

+24V DC / 5A
